KRAL Screw Pumps for Transfer Applications.

The economical solution for the delivery of oils.

KRAL screw pumps are in demand thanks to their compact design. In operation, our pumps are quiet, offer low pulsation and are highly efficient.

KRAL pumps are especially suitable for the transfer of oils. The pumps can handle a wide range of viscosities and differential pressures. With a high flow rate and an excellent NPSH value, KRAL screw pumps are manufactured in accordance with European and American standards.

KRAL three screws pumps offer a significant price advantage compared to other types of pumps and are used to flush the pipe system with separated crude oil from the storage tanks on a regular basis. KRAL two screw pumps also deliver aggressive and contaminated liquids.

Our screw pumps are well suited for pipeline booster applications in pumping stations. Due to their design, KRAL pumps can handle oils with a
wide range of viscosities and can generate high differential pressures even when pumping very light oils.

Transfer pumps application examples.

Transfer of crude oil and separated crude oil.
Loading and unloading pumps for transfer systems.

Advantages of KRAL screw pumps.

Meet API standards.
Economically priced.
Quiet, no vibration and low pulsation.
Great suction lift.
High efficiency and durability.
Simple construction.
For low and high viscosity.
Easy maintenance.

Product recommendations.

K series.

Delivery rate: 5 to 2,900 l/min.
Max. differential pressure: 16 bar.
Temperature range: -20 °C to 180 °C, magnetic coupling to 300 °C.
Housing: Nodular cast iron EN-GJS-400.
Screws: Steel, nitrided.
Approvals: ABS, BV, CCS, DNV, GL, LRS, MRS, NK, RINA.
ATEX: II 2 GD b/c group II,
category 2.
Heating: Electrical, media or steam.

screw pump series C in horizontal installation

C series.

Delivery rate: CK: 5 to 1,750 l/min / CL & CG: 5 to 3,550 l/min.
Temperature range: -20 °C to 180 °C, magnetic coupling to 300 °C.
Pressure range: 70 bar; 100 bar.
Housing: Nodular cast iron, steel and aluminium.
Screws: Steel, nitrided.
Approvals: ABS, BV, CCS, DNV, GL, LRS, MRS, NK, RINA, KR.
ATEX: II 2 GD b/c group II,
category 2.
Heating: Electrical, media or steam.
API: Manufactured to conform
with API.

all connections are possible horizontally (inline) and in different angles

Z series.

Delivery rate: 330 to 17,660 l/min or 20 to 1,060 m³/h.
Max. differential pressure: 25 bar.
Temperature range: -40 °C to +300 °C.
Housing: Ductile iron or welded steel.
Screws: Solid or engineered.
Approvals: ABS, BV, DNV/GL, LRS, RINA, others on request.
ATEX: II 2 GD b/c group II, category 2.
Heating: Electrical, media or steam.
API: Manufacturing according to API 676 possible.
